Oil spectrometer PO100

Part Number: PO100

The PO100 is a rotating-disc electrode (RDE) optical emission spectrometer tailored for direct, rapid elemental analysis of lubricating and hydraulic oils. It delivers multi-element testing (typically 24 elements, expandable to 32) in approximately 30–35 seconds, with no dilution or carrier gases needed. PO100 meets industry standards such as ASTM D6595, ASTM D6728, NB/SH/T0865-2013, and HB20094.1-2012


                                                    High-Speed Testing in ~30 Seconds

                                                Enables fast condition monitoring with elemental results delivered in just half a minute .


                                                    Wide Element Range & Expandability

                                                Standard includes analysis of 24 common wear and contaminant elements; configurable to up to 32 .


                                                    Precise Optics & Stable Light Source

                                                Employs Paschen–Runge optical design, 500 mm focal length, and digital arc control for stable excitation and consistent performance .


                                                    Integrated Software – WinOil V1.0

                                                Features intuitive GUI, auto-standardization, data export (USB), barcode reading, printing, and advanced analytical metrics (e.g. RSD, standard deviation) .


                                                    Low Maintenance & Portable Design

                                                Built-in disc sharpener and long-life arc source ensure minimal upkeep. Compact (770 × 360 × 540 mm) and weighs ~55 kg .

Specification	Value
Test Speed	~30–35 seconds per run
Optical Configuration	Paschen–Runge + Rowland circle; 500 mm focal length
Wavelength Range	190–800 nm
Detector	CCD, 3648 pixels/channel
Detectable Elements	24 standard, up to 32 optional
Detection Limit	< 1 ppm
Power Supply	AC 220 V ±10%, 50–60 Hz, 10 A, ~1.5 kVA
Dimensions (L×W×H)	770 × 360 × 540 mm
Weight	~55 kg
