X-MAX II handheld X-ray fluorescence spectrometer
Metal Analysis Handheld Elemental Analysis

X-MAX II handheld X-ray fluorescence spectrometer

Part Number: X-MAX II
The X‑MAX II is Soohow’s latest-generation handheld XRF, featuring over 12 years of R&D expertise. Weighing just 1.65 kg (with battery), it integrates a powerful X-ray microtube with selectable targets (Au, Ag, W, Ta, Pd) and a cooled Si-PIN (or optional SDD) detector. Onboard Windows CE6.0 and intuitive software (“X‑MAN II Alloy Plus 6.0”) deliver lightning-fast, non-destructive alloy identification—often in ≤1 second. It’s built for rugged environments and precision testing in hard-to-reach spots and welds.
Ultra-Light & Fast
At just 1.65 kg, it’s the lightest handheld XRF gun from Soohow, delivering full multi-element analysis in under a second.
Versatile Target Options
Choose from 5 X-ray tube targets (Au, Ag, W, Ta, Pd) and use automatic filters to optimize for different material types.

Powered & Precise
Operates at variable voltages (35–50 kV), with a Peltier-cooled Si-PIN detector (SDD in advanced models) for quality resolution.
Rugged & Intuitive UI
Touchscreen TFT runs Windows CE6.0, supports easy one-click operation, fast data transfer via USB, and houses up to 32 GB for 80 k+ test records.
Safety by Design
Features automatic X‑ray shut-off without a sample, aluminum alloy shielding (6061), and meets global safety standards.
Industrial-Grade Build
IP-rated for dust, water, freeze, and vibration resistance—ideal for field and industrial workshops.
Specification Value
Weight 1.50 kg (host); 1.65 kg with battery
1.50 kg (host); 1.65 kg with battery 250 × 75 × 270 mm
X‑ray Tube 35–50 kV, high-power microtube with 5 target options
Detector Cooled Si‑PIN; SDD optional
Filter System Auto-select filters tailored for test objects
Battery Two 7.2 V / 6,600 mAh Li-ion packs
OS & Software Windows CE6.0; X‑MAN II Alloy Plus 6.0
Memory & Storage 32 GB memory card (≈ 80,000+ records)
Display Industrial HD TFT touchscreen, high visibility in all light
Safety Features Auto shut-off, radiation shielding with aluminum alloy housing
