JKJQ‑3 Dielectric Strength Tester

Part Number: JKJQ‑3

The JKJQ‑3 is a fully automatic single-cup dielectric breakdown tester designed for testing transformer, capacitor, and insulating oils. Using microprocessor control, it automates the entire test cycle—voltage ramp‑up (up to 80 kV standard), hold, stirring, breakdown detection, discharge, calculation, printing, and data storage—delivering consistent and accurate results with minimal user interaction. Built for both field and laboratory use to ensure oil quality, safety, and compliance with national testing standards.


                                                    Microprocessor-Controlled Full Automation

                                                Automates the entire dielectric test cycle—including voltage ramp‑up, hold, stirring, breakdown detection, and discharge—for reliable and repeatable performance.


                                                     High Precision with Auto Recording

                                                Powers samples to as high as 80 kV (standard), with low distortion and integrated data storage—keeping up to 100 results for reporting and traceability.


                                                    Operator Safety & Ease of Use

                                                Features built-in protections for over‑voltage, over‑current, electrode limit detection, plus automatic discharge and simplified controls via an LCD interface—enhancing safety during high-voltage tests.

Specification	Value
Voltage Range	0–80 kV AC (standard); optionally up to 100 kV
Voltage Accuracy	±3%; Voltage distortion ≤ 3%
Voltage Ramp-up Speed	Adjustable (approx. 0.5–5 kV/s)
Test Cycles	1–6 breakdowns per test
Display & Interface	LCD touchscreen, multilingual menu; RS‑232/USB; printer
Memory Capacity	Stores approx. 100 test records
Power Requirements	AC 220 V ±10%, 50/60 Hz, ~200–300 W
Operating Range	0–45 °C; Humidity < 85% RH
Sample Cup Size	Approximately 300–500 mL
Dimensional/Weight	~430×350×370 mm and around 26 kg
